Genway WL-03NL-V2 Digital Intercom Panel with Card Reader, Polish Voice

Price: 95,43 €
Tax included
Buy Genway WL-03NL-V2 digital intercom panel with card reader, alphanumeric keypad, Polish voice guidance, and flush-mount design. Ideal for multi-family buildings.

The Genway WL-03NL-V2 is a digital intercom panel designed for multi-family buildings with up to 400 users. It features a vandal-resistant aluminum housing, a built-in display, and a backlit alphanumeric keypad. The system supports proximity card access (125 kHz) and individual unlock codes, with Polish voice guidance for user-friendly operation.

  • Vandal-resistant aluminum casing for durability
  • Supports up to 400 users with modular 4-wire bus system
  • Built-in 125 kHz card reader for tags, key fobs, or stickers
  • Polish voice prompts guide visitors through key presses and door opening
  • 6 selectable ringer tones and adjustable volume for speech and ringer
  • Flush-mount design with dimensions 331 x 134 x 45 mm
  • Wide operating temperature range -40°C to +70°C

This intercom panel connects to audio modules via a 4-wire bus and to handset units via 2-wire (or 4-wire for speaker units). It includes an NO relay for electric strike control and allows door opening via individual code or proximity tag. Ideal for new installations or upgrades in residential and commercial buildings.

  • Reference
    WL-03NL-V2
  • In stock
    999 Items
  • MPN
    WL-03NL-V2

  • Power supply
    12-13.5 VDC
  • Operating temperature
    -40 to +70 °C
  • Housing material
    Aluminum
  • Mounting
    Flush-mounted
  • Display
    Built-in
  • Unlock methods
    Individual code, proximity tag
  • Panel dimensions
    331 x 134 x 45 mm
  • Warranty
    2 years
  • Keypad
    Alphanumeric backlit
  • Max users
    400
  • Brand
    Genway
  • Model
    WL-03NL-V2
  • SKU
    WL-03NL-V2
  • Product Type
    Digital Intercom Panel with Card Reader
  • Card Reader Frequency
    125 kHz
  • Card Reader Standard
    Unique 125kHz
  • Voice Guidance
    Polish
  • Connection External Panel to Audio Module
    4-wire bus
  • Connection Audio Module to Handset Units
    2-wire
  • Connection Audio Module to Speaker Units
    4-wire
  • Max Cable Length (0.75mm²)
    50 m
  • Max Cable Length (1.0mm²)
    100 m
  • Electric Strike Control
    NO relay
  • Volume Control
    Speech and ringer
  • Ringer Tones
    6 selectable
  • Current Consumption Standby
    ≤70 mA
  • Current Consumption Active
    ≤250 mA
  • Max Humidity
    90 %
  • Back Box Dimensions
    325 x 117 x 35 mm
