Hager ADS906D RCBO 1P+N 6kA B-6A 30mA Type A

The Hager ADS906D is a combined residual current circuit breaker with overcurrent protection (RCBO) designed for 1P+N applications. It offers a rated current of 6A, a B tripping curve, and a 6kA breaking capacity. The integrated RCD provides 30mA Type A residual current protection, making it suitable for circuits requiring both overcurrent and earth fault protection.

• 1P+N configuration – protects a single phase and neutral
• Rated current 6A – ideal for lighting or small load circuits
• B curve – for resistive or low inrush loads
• 6kA breaking capacity – suitable for residential and light commercial installations
• 30mA Type A RCD – detects sinusoidal and pulsating DC fault currents
• DIN rail mounting – easy installation in distribution boards

Use the Hager ADS906D to combine overcurrent and residual current protection in a single compact device, saving space and simplifying wiring.
