Hager AD916J RCBO 1P+N 6kA B-16A 30mA AC

Hager AD916J RCBO 1P+N 6kA B-16A 30mA AC

50,70 €
AR PVN
Hager AD916J RCBO, 1P+N, 6kA breaking capacity, B curve 16A, 30mA AC residual current. Reliable protection for your electrical circuits.

The Hager AD916J is a high-quality RCBO (Residual Current Circuit Breaker with Overcurrent Protection) combining overcurrent and residual current protection in a single compact device. Rated at 16A with a B trip curve, it is ideal for protecting lighting and general-purpose circuits in residential and commercial installations.

  • 1P+N pole configuration for single-phase systems
  • 6kA breaking capacity (Icn) ensures safety under fault conditions
  • 30mA AC residual current sensitivity protects against electric shock
  • Easy DIN rail mounting for quick installation
  • Compliant with international standards for reliable performance

Use the Hager AD916J as a combined MCB/RCD solution to save space in your distribution board while ensuring comprehensive protection.

  • Norāde
    AD916J
  • Pieejamās vispirms
    800 vienības:
  • ean13
    3250611040712
  • MPN
    AD916J

  • IP rating
    IP20
  • Mounting
    DIN rail 35mm
  • Poles
    1P+N
  • Trip curve
    B
  • Rcd type
    AC
  • Terminal type
    Screw
  • Brand
    Hager
  • SKU
    AD916J
  • Product Type
    RCBO
  • EAN
    3250611040712
  • Model / Reference
    AD916J
  • Breaking Capacity (Icn)
    6 kA
  • Rated Current (In)
    16 A
  • Residual Current (IΔn)
    30 mA
  • Rated Voltage (Ue)
    230V V
  • Rated Frequency
    50/60 Hz
  • Width (DIN Modules)
    2 module
  • Tripping / Time Delay Class
    Instantaneous
  • Rated Conditional Short-Circuit Current (Inc)
    6000 A
