Hager ECR140D 1-Phase kWh Meter Direct 80A 2M Modbus MID
Price:
136,21 €
AR PVN
Buy Hager ECR140D direct 80A kWh meter with Modbus communication, MID certified for billing. Ideal for submetering.
The Hager ECR140D is a 1-phase direct-connected kWh meter with a maximum current of 80A. It features Modbus communication for easy integration into building management systems. MID certified, it is suitable for billing and submetering applications. The meter occupies 2 DIN modules, making it compact for distribution boards.
- Direct measurement up to 80A without current transformers
- Modbus RTU communication for remote reading
- MID certified for legal metrology and billing
- 1-phase operation, 230V nominal voltage
- 2-module width for space-saving installation
Ideal for commercial and industrial submetering, the ECR140D provides accurate energy monitoring with easy integration.
-
NorādeECR140D
-
Pieejamās vispirms800 vienības:
-
ean133250612231423
-
MPNECR140D
-
Communication protocolModbus
-
Phases1-phase
-
MountingDIN rail
-
Connection typeDirect
-
Measurement channels1
-
Operating voltage230V
-
Din modules width2M module
-
BrandHager
-
ModelECR140D
-
SKUECR140D
-
Product TypeEnergy meter
-
EAN3250612231423
-
Max Measuring Current80 A
-
Bidirectional MeteringNo
-
MID CertifiedYes
