Hager ADS910D RCBO 1P+N 6kA B-10A 30mA Type A

Hager ADS910D is a combined residual current circuit breaker with overcurrent protection (RCBO) for 1P+N networks. It offers a rated current of 10A, B-curve tripping characteristic, and a breaking capacity of 6kA. The integrated RCD is Type A with a rated residual current of 30mA, providing protection against sinusoidal and pulsating DC fault currents.

• Compact design: 2 DIN modules width, suitable for standard 35mm DIN rail mounting.
• High breaking capacity: 6kA (Icn) ensures safe interruption of short-circuit currents.
• Type A RCD: Detects both AC and pulsating DC residual currents for enhanced safety.
• B-curve: Ideal for resistive and lighting loads with low inrush currents.
• Easy installation: Screw terminals for secure wiring.

Use the ADS910D in residential and commercial distribution boards to protect circuits against overloads, short circuits, and earth faults. Complies with relevant standards for reliable performance.
