Hager ADM432C RCBO 4P 6kA C-13A 30mA Type A

Hager ADM432C RCBO 4P 6kA C-13A 30mA Type A

135,97 €
AR PVN
Hager ADM432C RCBO: 4-pole, 13A C-curve, 30mA Type A, 6kA breaking capacity. Reliable protection for your electrical circuits. Shop now!

The Hager ADM432C is a 4-pole RCBO (Residual Current Circuit Breaker with Overcurrent Protection) combining overcurrent and residual current protection in one compact device. Rated at 13A with a C-curve trip characteristic and 30mA Type A residual current sensitivity, it offers reliable protection against overloads, short circuits, and earth faults.

  • 4-pole design for three-phase systems
  • Breaking capacity: 6kA (Icn)
  • Rated voltage: 230/400V AC, 50Hz
  • Width: 4 DIN modules
  • Mounting: DIN rail 35mm
  • Terminal type: Screw terminals
  • IP20 rated for indoor use

Ideal for distribution boards in residential and commercial installations, the Hager ADM432C ensures safety and compliance with modern electrical standards.

  • Norāde
    ADM432C
  • Pieejamās vispirms
    800 vienības:
  • ean13
    3250611020257
  • MPN
    ADM432C

  • IP rating
    IP20
  • Mounting
    DIN rail 35mm
  • Poles
    4P
  • Trip curve
    C
  • Rcd type
    A
  • Terminal type
    Screw
  • Brand
    Hager
  • SKU
    ADM432C
  • Product Type
    RCBO (combined)
  • EAN
    3250611020257
  • Model / Reference
    ADM432C
  • Breaking Capacity (Icn)
    6 kA
  • Rated Current (In)
    13 A
  • Residual Current (IΔn)
    30 mA
  • Rated Voltage (Ue)
    230/400V V
  • Rated Frequency
    50 Hz
  • Width (DIN Modules)
    4 module
  • Tripping / Time Delay Class
    Instantaneous
  • Rated Conditional Short-Circuit Current (Inc)
    6000 A
