Hager ADZ316D RCBO 1P+N 6kA B-16A 30mA Type A

The Hager ADZ316D is a combined residual current circuit breaker with overcurrent protection (RCBO), designed to provide both earth leakage and short-circuit/overload protection in a single module. This device is part of Hager's high-quality range, ensuring safety and reliability in residential and commercial installations.

• 1P+N configuration with B-curve tripping characteristic for 16A rated current
• 6kA breaking capacity (Icn) suitable for standard distribution boards
• 30mA residual current sensitivity with Type A RCD for AC and pulsating DC fault currents
• Compact design for easy installation on 35mm DIN rail
• Hager quality and compliance with international standards

Ideal for protecting circuits supplying socket outlets, lighting, and general appliances where both overcurrent and residual current protection are required. The ADZ316D combines two functions in one device, saving space in the consumer unit.
