VidiLine VIDI-AC-EZ1 Classic NC Electric Strike DC/AC 12V 0.7A

The VidiLine VIDI-AC-EZ1 is a classic NC (normally closed) electric strike designed for access control systems. In its resting state (no power), the door remains locked. When voltage is applied, the strike opens, allowing the door to be opened.

• Lock Type: Classic NC – fails locked
• Supply Voltage: DC/AC 12 V
• Rated Current: 700 mA
• Power Consumption: 8.4 W
• Dimensions: 67 × 17 × 28.6 mm
• Faceplate: Not included (compatible with VIDI-AC-SZ110 and VIDI-AC-SZ250 faceplates)
• Memory: No

Important: The maximum continuous operation time for Classic NC strikes is 10 minutes. The latch adjustment range is up to 3 mm.
