Hager ADS932D RCBO 1P+N 6kA B-32A 30mA Type A

Hager ADS932D RCBO 1P+N 6kA B-32A 30mA Type A

75,88 €
AR PVN
Hager ADS932D RCBO: 1P+N, 6kA breaking capacity, B-curve, 32A rated current, 30mA Type A RCD. Reliable protection for your electrical circuits.

The Hager ADS932D is a high-quality RCBO (Residual Current Circuit Breaker with Overcurrent Protection) combining overcurrent and earth leakage protection in a single device. Rated at 32A with a B-curve trip characteristic and 6kA breaking capacity, it is designed for residential and commercial applications. The integrated 30mA Type A RCD ensures protection against sinusoidal and pulsating DC fault currents.

  • 1P+N configuration for single-phase circuits
  • B-curve for general purpose and resistive loads
  • 6kA breaking capacity (Icn)
  • 30mA residual current sensitivity, Type A
  • Rated voltage 230V AC, frequency 50/60Hz
  • Width: 2 DIN modules, mounts on 35mm DIN rail
  • Screw terminals for secure wiring

Ideal for protecting circuits supplying sockets, lighting, and appliances, the Hager ADS932D offers reliable and compact protection. Comply with the latest electrical standards.

  • Norāde
    ADS932D
  • Pieejamās vispirms
    800 vienības:
  • ean13
    3250611068174
  • MPN
    ADS932D

  • IP rating
    IP20
  • Mounting
    DIN rail 35mm
  • Poles
    1P+N
  • Trip curve
    B
  • Rcd type
    A
  • Terminal type
    Screw
  • Brand
    Hager
  • SKU
    ADS932D
  • Product Type
    RCBO (combined)
  • EAN
    3250611068174
  • Model / Reference
    ADS932D
  • Breaking Capacity (Icn)
    6 kA
  • Rated Current (In)
    32 A
  • Residual Current (IΔn)
    30 mA
  • Rated Voltage (Ue)
    230V V
  • Rated Frequency
    50/60 Hz
  • Width (DIN Modules)
    2 module
  • Tripping / Time Delay Class
    Instantaneous
  • Rated Conditional Short-Circuit Current (Inc)
    6000 A
